Deep Groove Ball Bearings16000 series
Bearing Number | Boundary Dimensions(mm) | Basic Load Ratings(kN) | Limiting Speeds(rpm) | Mass(Kg) | |||||
QBT | d | D | B | rs min | Cr | Cor | Grease | Oil | (Approx.) |
16001 | 12 | 28 | 7 | 0.3 | 5.1 | 2.39 | 26,000 | 30,000 | 0.019 |
16002 | 15 | 32 | 8 | 0.3 | 5.6 | 2.83 | 22,000 | 26,000 | 0.025 |
16003 | 17 | 35 | 8 | 0.3 | 6.8 | 3.35 | 20,000 | 24,000 | 0.032 |
16004 | 20 | 42 | 8 | 0.3 | 7.9 | 4.5 | 18,000 | 21,000 | 0.051 |
16005 | 25 | 47 | 8 | 0.3 | 8.35 | 5.1 | 15,000 | 18,000 | 0.06 |
16006 | 30 | 55 | 9 | 0.3 | 11.2 | 7.35 | 13,000 | 15,000 | 0.091 |
16007 | 35 | 62 | 9 | 0.3 | 11.7 | 8.2 | 12,000 | 14,000 | 0.11 |
16008 | 40 | 68 | 9 | 0.3 | 12.6 | 9.65 | 10,000 | 12,000 | 0.125 |
16009 | 45 | 75 | 10 | 0.6 | 12.9 | 10.5 | 9,200 | 11,000 | 0.171 |
16010 | 50 | 80 | 10 | 0.6 | 13.2 | 11.3 | 8,400 | 9,800 | 0.18 |
16011 | 55 | 90 | 11 | 0.6 | 18.6 | 15.3 | 7,700 | 9,000 | 0.258 |
16012 | 60 | 95 | 11 | 0.6 | 20 | 17.5 | 7,000 | 8,300 | 0.283 |
16013 | 65 | 100 | 11 | 0.6 | 20.5 | 18.7 | 6,500 | 7,700 | 0.307 |
16014 | 70 | 110 | 13 | 0.6 | 24.4 | 22.6 | 6,100 | 7,100 | 0.441 |
16015 | 75 | 115 | 13 | 0.6 | 25 | 24 | 5,700 | 6,700 | 0.464 |
16016 | 80 | 125 | 14 | 0.6 | 25.4 | 25.1 | 5,300 | 6,200 | 0.597 |
16017 | 85 | 130 | 14 | 0.6 | 25.9 | 26.2 | 5,000 | 5,900 | 0.626 |
16018 | 90 | 140 | 16 | 1 | 33.5 | 33.5 | 4,700 | 5,600 | 0.848 |
16019 | 95 | 145 | 16 | 1 | 34.5 | 35 | 4,500 | 5,300 | 0.885 |
16020 | 100 | 150 | 16 | 1 | 35 | 36.5 | 4,200 | 5,000 | 0.91 |
