Deep Groove Ball Bearings 6800 series
Bearing Number | Boundary Dimensions(mm) | Basic Load Ratings(kN) | Limiting Speeds(rpm) | Mass(Kg) | |||||
QBT | d | D | B | rs min | Cr | Cor | Grease | Oil | (Approx.) |
6800 | 10 | 19 | 5 | 0.3 | 1.83 | 0.93 | 32,000 | 38,000 | 0.005 |
6801 | 12 | 21 | 5 | 0.3 | 1.92 | 1.04 | 29,000 | 35,000 | 0.006 |
6802 | 15 | 24 | 5 | 0.3 | 2.08 | 1.26 | 26,000 | 31,000 | 0.007 |
6803 | 17 | 26 | 5 | 0.3 | 2.23 | 1.46 | 24,000 | 28,000 | 0.008 |
6804 | 20 | 32 | 7 | 0.3 | 4 | 2.47 | 21,000 | 25,000 | 0.019 |
6805 | 25 | 37 | 7 | 0.3 | 4.3 | 2.95 | 18,000 | 21,000 | 0.022 |
6806 | 30 | 42 | 7 | 0.3 | 4.7 | 3.65 | 15,000 | 18,000 | 0.026 |
6807 | 35 | 47 | 7 | 0.3 | 4.9 | 4.05 | 13,000 | 16,000 | 0.029 |
6808 | 40 | 52 | 7 | 0.3 | 5.1 | 4.4 | 12,000 | 14,000 | 0.033 |
6809 | 45 | 58 | 7 | 0.3 | 5.35 | 4.95 | 11,000 | 12,000 | 0.04 |
6810 | 50 | 65 | 7 | 0.3 | 6.6 | 6.1 | 9,600 | 11,000 | 0.052 |
6811 | 55 | 72 | 9 | 0.3 | 8.8 | 8.1 | 8,700 | 10,000 | 0.083 |
6812 | 60 | 78 | 10 | 0.3 | 11.5 | 10.6 | 8,000 | 9,400 | 0.106 |
6813 | 65 | 85 | 10 | 0.6 | 11.6 | 11 | 7,400 | 8,700 | 0.128 |
6814 | 70 | 90 | 10 | 0.6 | 12.1 | 11.9 | 6,900 | 8,100 | 0.137 |
6815 | 75 | 95 | 10 | 0.6 | 12.5 | 12.9 | 6,400 | 7,600 | 0.145 |
