Cylindrical Roller Bearings NU series

Product Name:

Cylindrical Roller Bearings NU series

Model :

NU1005, NU1006, NU1007, NU1008, NU1009...

Product Description:

s-l1600 (6).jpg

s-l1600 (21).jpg timg (2)_meitu_2.jpg

Cylindrical Roller Bearings NU.NJ 10 series

Bearing Number		Boundary dimensions(mm)					Basic load ratings(kN)		Limiting speeds(rpm)		Mass(Kg)
QBT		d	D	B	rs min	rs1 min	Cr	Cor	Grease	Oil	(Approx.)
NU1005	NJ1005	25	47	12	0.6	0.3	15.1	14.1	16,000	19,000	0.092
NU1006	NJ1006	30	55	13	1	0.6	19.7	19.6	14,000	16,000	0.13
NU1007	NJ1007	35	63	14	1	0.6	22.6	23.2	12,000	15,000	0.179
NU1008	NJ1008	40	68	15	1	0.6	27.3	29	11,000	13,000	0.22
NU1009	NJ1009	45	75	16	1	0.6	31	34	9,900	12,000	0.28
NU1010	NJ1010	50	80	16	1	0.6	32	36	8,900	11,000	0.295
NU1011	NJ1011	55	90	18	1.1	1	37.5	44	8,200	9,700	0.442
NU1012	NJ1012	60	95	18	1.1	1	40	48.5	7,500	8,800	0.474
NU1013	NJ1013	65	100	18	1.1	1	41	51	7,000	8,200	0.485
NU1014	NJ1014	70	110	20	1.1	1	58.5	70.5	6,500	7,600	0.699
NU1015	NJ1015	75	115	20	1.1	1	60	74.5	6,100	7,100	0.738
NU1016	NJ1016	80	125	22	1.1	1	72.5	90.5	5,700	6,700	0.98
NU1017	NJ1017	85	130	22	1.1	1	74.5	95.5	5,400	6,300	1.03
NU1018	NJ1018	90	140	24	1.5	1.1	88	114	5,100	5,900	1.33
NU1019	NJ1019	95	145	24	1.5	1.1	90.5	120	4,800	5,600	1.4
NU1020	NJ1020	100	150	24	1.5	1.1	93	126	4,600	5,400	1.45
NU1021	NJ1021	105	160	26	2	1.1	105	142	4,300	5,100	1.84
NU1022	NJ1022	110	170	28	2	1.1	131	174	4,100	4,800	2.33
NU1024	NJ1024	120	180	28	2	1.1	139	191	3,800	4,400	2.44
NU1026	NJ1026	130	200	33	2	1.1	172	238	3,400	4,000	3.69

Cylindrical Roller Bearings NU.NJ 2 series

Bearing Number		Boundary Dimensions(mm)					Basic Load Ratings(kN)		Limiting Speeds(rpm)		Mass(Kg)
QBT		d	D	B	rs min	rs1 min	Cr	Cor	Grease	Oil	(Approx.)
NU204E	NJ204E	20	47	14	1	0.6	25.7	22.6	15,000	18,000	0.122
NU205E	NJ205E	25	52	15	1	0.6	29.3	27.7	13,000	15,000	0.151
NU206E	NJ206E	30	62	16	1	0.6	39	37.5	11,000	13,000	0.226
NU207E	NJ207E	35	72	17	1.1	0.6	50.5	50	9,500	11,000	0.327
NU208	NJ208	40	80	18	1.1	1.1	43.5	43	9,400	11,000	0.378
NU208E	NJ208E	40	80	18	1.1	1.1	55.5	55.5	8,500	10,000	0.426
NU209	NJ209	45	85	19	1.1	1.1	46	47	8,400	9,900	0.432
NU209E	NJ209E	45	85	19	1.1	1.1	63	66.5	7,600	9,000	0.495
NU210	NJ210	50	90	20	1.1	1.1	48	51	7,600	9,000	0.47
NU210E	NJ210E	50	90	20	1.1	1.1	66	72	6,900	8,100	0.54
NU211	NJ211	55	100	21	1.5	1.1	58	62.5	6,900	8,200	0.638
NU211E	NJ211E	55	100	21	1.5	1.1	82.5	93	6,300	7,400	0.718
NU212	NJ212	60	110	22	1.5	1.5	68.5	75	6,400	7,600	0.818
NU212E	NJ212E	60	110	22	1.5	1.5	97.5	107	5,800	6,800	0.923
NU213	NJ213	65	120	23	1.5	1.5	84	94.5	5,900	7,000	1.02
NU213E	NJ213E	65	120	23	1.5	1.5	108	119	5,400	6,300	1.21
NU214	NJ214	70	125	24	1.5	1.5	83.5	95	5,500	6,500	1.12
NU214E	NJ214E	70	125	24	1.5	1.5	119	137	5,000	5,900	1.3
NU215	NJ215	75	130	25	1.5	1.5	96.5	111	5,100	6,000	1.23
NU215E	NJ215E	75	130	25	1.5	1.5	130	156	4,700	5,500	1.41
NU216	NJ216	80	140	26	2	2	106	122	4,800	5,700	1.5
NU216E	NJ216E	80	140	26	2	2	139	167	4,400	5,100	1.67
NU217	NJ217	85	150	28	2	2	120	140	4,500	5,300	1.87
NU217E	NJ217E	85	150	28	2	2	167	199	4,100	4,800	2.11
NU218	NJ218	90	160	30	2	2	152	178	4,300	5,000	2.3
NU218E	NJ218E	90	160	30	2	2	182	217	3,900	4,600	2.44
NU219	NJ219	95	170	32	2.1	2.1	166	195	4,000	4,700	2.78
NU219E	NJ219E	95	170	32	2.1	2.1	220	265	3,600	4,300	3.02
NU220	NJ220	100	180	34	2.1	2.1	183	217	3,800	4,500	3.33
NU220E	NJ220E	100	180	34	2.1	2.1	249	305	3,500	4,100	3.66
NU221	NJ221	105	190	36	2.1	2.1	201	241	3,600	4,300	3.95
NU222	NJ222	110	200	38	2.1	2.1	240	290	3,400	4,000	4.63
NU224	NJ224	120	215	40	2.1	2.1	260	320	3,200	3,700	5.57
NU224E	NJ224E	120	215	40	2.1	2.1	335	420	2,900	3,400	5.97
NU226	NJ226	130	230	40	3	3	270	340	2,900	3,400	6.3
NU226E	NJ226E	130	230	40	3	3	365	455	2,600	3,100	6.9
NU228	NJ228	140	250	42	3	3	310	400	2,700	3,100	7.88
NU228E	NJ228E	140	250	42	3	3	395	515	2,400	2,800	8.73
NU230	NJ230	150	270	45	3	3	345	435	2,500	2,900	9.92
NU230E	NJ230E	150	270	45	3	3	450	595	2,200	2,600	11

Cylindrical Roller Bearings NU.NJ 22 series

Bearing Number		Boundary dimensions(mm)					Basic load ratings(kN)		Limiting speeds(rpm)		Mass(Kg)
QBT		d	D	B	rs min	rs1 min	Cr	Cor	Grease	Oil	(Approx.)
NU2204E	NJ2204E	20	47	18	1	0.6	30.5	28.3	14,000	16,000	0.158
NU2205E	NJ2205E	25	52	18	1	0.6	35	34.5	11,000	13,000	0.186
NU2206E	NJ2206E	30	62	20	1	0.6	49	50	9,700	11,000	0.297
NU2207E	NJ2207E	35	72	23	1.1	0.6	61.5	65.5	8,500	10,000	0.455
NU2208	NJ2208	40	80	23	1.1	1.1	58	62	8,500	10,000	0.49
NU2208E	NJ2208E	40	80	23	1.1	1.1	72.5	77.5	7,600	8,900	0.552
NU2209	NJ2209	45	85	23	1.1	1.1	61.5	68	7,600	9,000	0.53
NU2209E	NJ2209E	45	85	23	1.1	1.1	76	84.5	6,800	8,000	0.6
NU2210	NJ2210	50	90	23	1.1	1.1	64	73.5	6,900	8,100	0.571
NU2210E	NJ2210E	50	90	23	1.1	1.1	79.5	91.5	6,200	7,300	0.652
NU2211	NJ2211	55	100	25	1.5	1.1	75.5	87	6,300	7,400	0.773
NU2211E	NJ2211E	55	100	25	1.5	1.1	97	114	5,600	6,600	0.968
NU2212	NJ2212	60	110	28	1.5	1.5	96	116	5,800	6,800	1.06
NU2212E	NJ2212E	60	110	28	1.5	1.5	131	157	5,200	6,100	1.21
NU2213	NJ2213	65	120	31	1.5	1.5	120	149	5,400	6,300	1.4
NU2213E	NJ2213E	65	120	31	1.5	1.5	149	181	4,800	5,600	1.6
NU2214	NJ2214	70	125	31	1.5	1.5	119	151	5,000	5,900	1.47
NU2214E	NJ2214E	70	125	31	1.5	1.5	156	194	4,500	5,200	1.7
NU2215	NJ2215	75	130	31	1.5	1.5	130	162	4,700	5,500	1.55
NU2215E	NJ2215E	75	130	31	1.5	1.5	162	207	4,200	4,900	1.79
NU2216	NJ2216	80	140	33	2	2	147	186	4,400	5,100	1.93
NU2216E	NJ2216E	80	140	33	2	2	186	243	3,900	4,600	2.12
NU2217	NJ2217	85	150	36	2	2	170	218	4,100	4,800	2.44
NU2217E	NJ2217E	85	150	36	2	2	217	279	3,700	4,300	2.68
NU2218	NJ2218	90	160	40	2	2	197	248	3,900	4,600	3.1
NU2218E	NJ2218E	90	160	40	2	2	242	315	3,500	4,100	3.33
NU2219	NJ2219	95	170	43	2.1	2.1	230	298	3,600	4,300	3.79
NU2219E	NJ2219E	95	170	43	2.1	2.1	286	370	3,300	3,800	4.14
NU2220	NJ2220	100	180	46	2.1	2.1	258	340	3,500	4,100	4.57
NU2220E	NJ2220E	100	180	46	2.1	2.1	335	445	3,100	3,600	5.01
NU2222	NJ2222	110	200	53	2.1	2.1	320	415	3,100	3,700	6.56
NU2222E	NJ2222E	110	200	53	2.1	2.1	385	515	2,800	3,300	7.4
NU2224	NJ2224	110	200	38	2.1	2.1	293	365	3,100	3,700	4.27
NU2224E	NJ2224	120	215	58	2.1	2.1	350	460	2,900	3,400	8.19
NU2224E	NJ2224E	120	215	58	2.1	2.1	450	620	2,600	3,000	9.18
NU2226	NJ2226	130	230	64	3	3	380	530	2,600	3,100	10.2
NU2226E	NJ2226E	130	230	64	3	3	530	735	2,300	2,700	11.8
NU2228	NJ2228	140	250	68	3	3	445	635	2,400	2,800	12.9
NU2228E	NJ2228E	140	250	68	3	3	575	835	2,100	2,500	15.8
NU2230	NJ2230	150	270	73	3	3	500	710	2,200	2,600	16.3
NU2230E	NJ2230E	150	270	73	3	3	660	980	2,000	2,400	19.7

Cylindrical Roller Bearings NU.NJ 3 series

Bearing Number		Boundary dimensions(mm)					Basic load ratings(kN)		Limiting speeds(rpm)		Mass(Kg)
QBT		d	D	B	rs min	rs1 min	Cr	Cor	Grease	Oil	(Approx.)
NU304E	NJ304E	20	52	15	1.1	0.6	31.5	26.9	13,000	15,000	0.176
NU305E	NJ305E	25	62	17	1.1	1.1	41.5	37.5	11,000	13,000	0.275
NU306E	NJ306E	30	72	19	1.1	1.1	53	50	9,300	11,000	0.398
NU307E	NJ307E	35	80	21	1.5	1.1	71	71	8,100	9,600	0.545
NU308	NJ308	40	90	23	1.5	1.5	58.5	57	8,000	9,400	0.658
NU308E	NJ308E	40	90	23	1.5	1.5	83	81.5	7,200	8,500	0.754
NU309	NJ309	45	100	25	1.5	1.5	74	71	7,200	8,400	0.877
NU309E	NJ309E	45	100	25	1.5	1.5	97.5	98.5	6,500	7,600	0.996
NU310	NJ310	50	110	27	2	2	87	86	6,500	7,700	1.14
NU310E	NJ310E	50	110	27	2	2	110	113	5,900	6,900	1.3
NU311	NJ311	55	120	29	2	2	111	111	5,900	7,000	1.45
NU311E	NJ311E	55	120	29	2	2	137	143	5,300	6,300	1.65
NU312	NJ312	60	130	31	2.1	2.1	124	126	5,500	6,500	1.8
NU312E	NJ312E	60	130	31	2.1	2.1	150	157	4,900	5,800	2.05
NU313	NJ313	65	140	33	2.1	2.1	135	139	5,100	6,000	2.23
NU313E	NJ313E	65	140	33	2.1	2.1	181	191	4,600	5,400	2.54
NU314	NJ314	70	150	35	2.1	2.1	158	168	4,700	5,500	2.71
NU314E	NJ314E	70	150	35	2.1	2.1	205	222	4,200	5,000	3.1
NU315	NJ315	75	160	37	2.1	2.1	190	205	4,400	5,200	3.28
NU315E	NJ315E	75	160	37	2.1	2.1	240	263	4,000	4,700	3.74
NU316	NJ316	80	170	39	2.1	2.1	190	207	4,100	4,800	3.86
NU316E	NJ316E	80	170	39	2.1	2.1	256	282	3,700	4,400	4.22
NU317	NJ317	85	180	41	3	3	212	228	3,900	4,600	4.54
NU317E	NJ317E	85	180	41	3	3	291	330	3,500	4,100	4.81
NU318	NJ318	90	190	43	3	3	240	265	3,700	4,300	5.3
NU318E	NJ318E	90	190	43	3	3	315	355	3,300	3,900	5.72
NU319	NJ319	95	200	45	3	3	259	285	3,400	4,000	6.13
NU319E	NJ319E	95	200	45	3	3	335	385	3,100	3,600	6.62
NU320	NJ320	100	215	47	3	3	299	335	3,300	3,800	7.49
NU320E	NJ320E	100	215	47	3	3	380	425	2,900	3,500	8.57
NU321	NJ321	105	225	49	3	3	320	360	3,100	3,700	8.53
NU322	NJ322	110	240	50	3	3	360	400	3,000	3,500	10
NU322E	NJ322E	110	240	50	3	3	450	525	2,700	3,100	11.1
NU324	NJ324	120	260	55	3	3	450	510	2,700	3,200	12.8
NU324E	NJ324E	120	260	55	3	3	530	610	2,400	2,800	13.9
NU326	NJ326	130	280	58	4	4	560	665	2,500	2,900	17.4
NU326E	NJ326E	130	280	58	4	4	615	735	2,200	2,600	19.4
NU328	NJ328	140	300	62	4	4	615	745	2,300	2,700	21.2
NU328E	NJ328E	140	300	62	4	4	665	795	2,100	2,400	23.2
NU330	NJ330	150	320	65	4	4	665	805	2,100	2,500	25.3
NU330E	NJ330E	150	320	65	4	4	760	920	1,900	2,300	28.4

Cylindrical Roller Bearings NU.NJ 23 series

Bearing Number		Boundary dimensions(mm)					Basic load ratings(kN)		Limiting speeds(rpm)		Mass(Kg)
QBT		d	D	B	rs min	rs1 min	Cr	Cor	Grease	Oil	(Approx.)
NU2304E	NJ2304E	20	52	21	1.1	0.6	42	39	12,000	14,000	0.242
NU2305E	NJ2305E	25	62	24	1.1	1.1	57	56	9,700	11,000	0.386
NU2306E	NJ2306E	30	72	27	1.1	1.1	74.5	77.5	8,300	9,700	0.58
NU2307E	NJ2307E	35	80	31	1.5	1.1	99	109	7,200	8,500	0.78
NU2308	NJ2308	40	90	33	1.5	1.5	82.5	88	7,000	8,200	0.951
NU2308E	NJ2308E	40	90	33	1.5	1.5	114	122	6,400	7,500	1.06
NU2309	NJ2309	45	100	36	1.5	1.5	99	104	6,300	7,400	1.27
NU2309E	NJ2309E	45	100	36	1.5	1.5	137	153	5,700	6,800	1.41
NU2310	NJ2310	50	110	40	2	2	121	131	5,700	6,700	1.7
NU2310E	NJ2310E	50	110	40	2	2	163	187	5,200	6,100	1.9
NU2311	NJ2311	55	120	43	2	2	148	162	5,200	6,100	2.17
NU2311E	NJ2311E	55	120	43	2	2	201	233	4,700	5,600	2.37
NU2312	NJ2312	60	130	46	2.1	2.1	169	188	4,800	5,700	2.71
NU2312E	NJ2312E	60	130	46	2.1	2.1	222	262	4,400	5,200	2.96
NU2313	NJ2313	65	140	48	2.1	2.1	188	212	4,400	5,200	3.27
NU2313E	NJ2313E	65	140	48	2.1	2.1	248	287	4,100	4,800	3.48
NU2314	NJ2314	70	150	51	2.1	2.1	223	262	4,100	4,800	3.98
NU2314E	NJ2314E	70	150	51	2.1	2.1	274	325	3,800	4,400	4.25
NU2315	NJ2315	75	160	55	2.1	2.1	258	300	3,800	4,500	4.87
NU2315E	NJ2315E	75	160	55	2.1	2.1	330	395	3,500	4,100	5.25
NU2316	NJ2316	80	170	58	2.1	2.1	274	330	3,600	4,200	5.79
NU2316E	NJ2316E	80	170	58	2.1	2.1	355	430	3,300	3,900	6.25
NU2317	NJ2317	85	180	60	3	3	315	380	3,400	4,000	6.7
NU2317E	NJ2317E	85	180	60	3	3	395	485	3,100	3,700	7.16
NU2318	NJ2318	90	190	64	3	3	325	395	3,200	3,800	7.95
NU2318E	NJ2318E	90	190	64	3	3	435	535	2,900	3,400	8.56
NU2319	NJ2319	95	200	67	3	3	370	460	3,000	3,500	9.2
NU2319E	NJ2319E	95	200	67	3	3	460	585	2,700	3,200	9.8
NU2320	NJ2320	100	215	73	3	3	410	505	2,900	3,400	11.7
NU2320E	NJ2320E	100	215	73	3	3	570	715	2,600	3,100	12.8
NU2322	NJ2322	110	240	80	3	3	605	790	2,600	3,100	17.1
NU2322E	NJ2322E	110	240	80	3	3	675	880	2,400	2,800	19.4
NU2324	NJ2324	120	260	86	3	3	710	920	2,400	2,800	21.5
NU2324E	NJ2324E	120	260	86	3	3	795	1,030	2,200	2,500	26.1
NU2326	NJ2326	130	280	93	4	4	840	1,130	2,200	2,600	26.9
NU2326E	NJ2326E	130	280	93	4	4	920	1,230	2,000	2,300	30.9
NU2328	NJ2328	140	300	102	4	4	920	1,250	2,000	2,300	33.8
NU2328E	NJ2328E	140	300	102	4	4	1,020	1,380	1,800	2,100	38.7
NU2330	NJ2330	150	320	108	4	4	1,020	1,400	1,900	2,200	40.6
NU2330E	NJ2330E	150	320	108	4	4	1,160	1,600	1,700	2,000	47.2
