Angular Contact Ball Bearings 70,72,73 single row series
Bearing Number | d | D | B | rmin | r1min |
7000C | 10 | 26 | 8 | 0.3 | 0.15 |
7001C | 12 | 28 | 8 | 0.3 | 0.15 |
7002C | 15 | 32 | 9 | 0.3 | 0.15 |
7003C | 17 | 35 | 10 | 0.3 | 0.15 |
7004C | 20 | 42 | 12 | 0.6 | 0.15 |
7005C | 25 | 47 | 12 | 0.6 | 0.15 |
7006C | 30 | 55 | 13 | 1 | 0.3 |
7007C | 35 | 62 | 14 | 1 | 0.3 |
7008C | 40 | 68 | 15 | 1 | 0.3 |
7009C | 45 | 75 | 16 | 1 | 0.3 |
7010C | 50 | 80 | 16 | 1 | 0.3 |
7011C | 55 | 90 | 18 | 1.1 | 0.6 |
7012C | 60 | 95 | 18 | 1.1 | 0.6 |
7013C | 65 | 100 | 18 | 1.1 | 0.6 |
7014C | 70 | 110 | 20 | 1.1 | 0.6 |
7015C | 75 | 115 | 20 | 1.1 | 0.6 |
7016C | 80 | 125 | 22 | 1.1 | 0.6 |
7017C | 85 | 130 | 22 | 1.1 | 0.6 |
7018C | 90 | 140 | 24 | 1.5 | 0.6 |
7019C | 95 | 145 | 24 | 1.5 | 0.6 |
7020C | 100 | 150 | 24 | 1.5 | 0.6 |
7200C | 10 | 30 | 9 | 0.6 | 0.15 |
7201C | 12 | 32 | 10 | 0.6 | 0.15 |
7202C | 15 | 35 | 11 | 0.6 | 0.15 |
7203C | 17 | 40 | 12 | 0.6 | 0.3 |
7204C | 20 | 47 | 14 | 1 | 0.3 |
7205C | 25 | 52 | 15 | 1 | 0.3 |
7206C | 30 | 62 | 16 | 1 | 0.3 |
7207C | 35 | 72 | 17 | 1.1 | 0.6 |
7208C | 40 | 80 | 18 | 1.1 | 0.6 |
7209C | 45 | 85 | 19 | 1.1 | 0.6 |
7210C | 50 | 90 | 20 | 1.1 | 0.6 |
7211C | 55 | 100 | 21 | 1.5 | 0.6 |
7212C | 60 | 110 | 22 | 1.5 | 0.6 |
7213C | 65 | 120 | 23 | 1.5 | 0.6 |
7214C | 70 | 125 | 24 | 1.5 | 0.6 |
7215C | 75 | 130 | 25 | 1.5 | 0.6 |
7216C | 80 | 140 | 26 | 2 | 1 |
7217C | 85 | 150 | 28 | 2 | 1 |
7218C | 90 | 160 | 30 | 2 | 1 |
7219C | 95 | 170 | 32 | 2.1 | 1.1 |
7220C | 100 | 180 | 34 | 2.1 | 1.1 |
7301C | 12 | 37 | 12 | 1 | 0.3 |
7302C | 15 | 42 | 13 | 1 | 0.3 |
7303C | 17 | 47 | 14 | 1 | 0.3 |
7304C | 20 | 52 | 15 | 1.1 | 0.6 |
7305C | 25 | 62 | 17 | 1.1 | 0.6 |
7306C | 30 | 72 | 19 | 1.1 | 0.6 |
7307C | 35 | 80 | 21 | 1.5 | 0.6 |
7308C | 40 | 90 | 23 | 1.5 | 0.6 |
7309C | 45 | 100 | 25 | 1.5 | 0.6 |
7310C | 50 | 110 | 27 | 2 | 1 |
7311C | 55 | 120 | 29 | 2 | 1 |
7312C | 60 | 130 | 31 | 2.1 | 1.1 |
7313C | 65 | 140 | 33 | 2.1 | 1.1 |
7314C | 70 | 150 | 35 | 2.1 | 1.1 |
7315C | 75 | 160 | 37 | 2.1 | 1.1 |
7316C | 80 | 170 | 39 | 2.1 | 1.1 |
7317C | 85 | 180 | 41 | 3 | 1.1 |
7318C | 90 | 190 | 43 | 3 | 1.1 |
7319C | 95 | 200 | 45 | 3 | 1.1 |
7320C | 100 | 215 | 47 | 3 | 1.1 |
Bearing Number | d | D | B | rmin | r1min |
7204B | 20 | 47 | 14 | 1 | 0.3 |
7205B | 25 | 52 | 15 | 1 | 0.3 |
7206B | 30 | 62 | 16 | 1 | 0.3 |
7207B | 35 | 72 | 17 | 1.1 | 0.6 |
7208B | 40 | 80 | 18 | 1.1 | 0.6 |
7209B | 45 | 85 | 19 | 1.1 | 0.6 |
7210B | 50 | 90 | 20 | 1.1 | 0.6 |
7211B | 55 | 100 | 21 | 1.5 | 0.6 |
7212B | 60 | 110 | 22 | 1.5 | 0.6 |
7213B | 65 | 120 | 23 | 1.5 | 0.6 |
7214B | 70 | 125 | 24 | 1.5 | 0.6 |
7215B | 75 | 130 | 25 | 1.5 | 0.6 |
7305B | 25 | 62 | 17 | 1.1 | 0.6 |
7306B | 30 | 72 | 19 | 1.1 | 0.6 |
7307B | 35 | 80 | 21 | 1.5 | 0.6 |
7308B | 40 | 90 | 23 | 1.5 | 0.6 |
7309B | 45 | 100 | 25 | 1.5 | 0.6 |
7310B | 50 | 110 | 27 | 2 | 1 |
7311B | 55 | 120 | 29 | 2 | 1 |
7312B | 60 | 130 | 31 | 2.1 | 1.1 |
7313B | 65 | 140 | 33 | 2.1 | 1.1 |
7314B | 70 | 150 | 35 | 2.1 | 1.1 |
7315B | 75 | 160 | 37 | 2.1 | 1.1 |
